FrontSuspensionComponentsSTEERINGANDFRONTSUSPENSION
9.8.Afterthetoe-inadjustmentismadeandwithwheelsinthestraightaheadposition,thesteeringwheel
shouldbeatthecenterofitstravel.Thereshouldbeequaltraveltotheleftandright.
FRONTSUSPENSIONCOMPONENTS
SeeGeneralWarningsonpage1-2.
TIERODENDREMOVAL
1.Disablethevehicle.
2.ElectricVehicle:Disconnectthebatteriesanddischargethecontroller.
GasolineVehicle:Disconnectthebatteryandsparkplugwire.
3.Loosenthejamnuts(1)(Figure7-13).
1
4
3
2
1311B
Figure7-13TieRodEndRemoval
4.Removetheretainingnuts(2).
5.Liftthetierod(3)fromtheholeinthespindletab.
6.Removethetierodendsfromthedraglink.
7.Applyalightcoatofanti-seizelubricatingcompoundtothethreads(4).
TIERODINSTALLATION
1.Installtierodends(3)ontothedraglink(4)toadepthof1/2inch(12.5mm)(Figure7-14).
WARNING
•Thetierodendsmustbethreadedintotherodatleast5/16ofaninch(8mm).Failuretothreaddeep
enoughmaycausetierodendstoseparatefromtherodduringadjustmentorwhilebeingoperated,
possiblyresultinginlossofvehiclecontrolandseverepersonalinjury.
Page7-122020Precedent,Villager2and4MaintenanceandServiceManual

Club Car Precedent Specifications

General

Power Source	Electric
Batteries	Six 8-volt (Electric)
Brakes	Mechanical Drum
Seating Capacity	2
Overall Length	91.5 in
Overall Width	47 in
Range	Up to 30 miles (depending on conditions)
Frame	Aluminum
Suspension	Leaf spring (front and rear)
Tires	18 x 8.5-8
Payload Capacity	800 lb
