Club Car Precedent Maintenance And Service Manual

ELECTRICVEHICLE-ELECTRICAL
COMPONENTSTow/RunSwitch
13
1
3
5
2
4
707
Figure13-8AccessandRemoveElectronicsModuleCover
TOW/RUNSWITCH
SeeGeneralWarningsonpage1-2.
TESTINGTHETOW/RUNSWITCH
SeeTestProcedure3–Tow/RunSwitchonpage12-15.
TOW/RUNSWITCHREMOVAL
1.Disconnectthebatteriesanddischargethecontroller.SeeDisconnecttheBatteries–ElectricVehicles
onpage1-4.
2.RemovetheelectronicsmodulecovertoaccessbacksideoftheT ow/Runswitch(2).SeeElectronicsModule
CoverRemovalonpage13-6.
3.RemoveT ow/Runswitchboot/hexnut(1)(Figure13-9,Page13-8).
4.RemoveTow/Runswitch(2)fromelectronicsmoduleanddisconnectthepinkwire(3)andlightgreenwire(4).
TOW/RUNSWITCHINSTALLATION
1.Installationisreverseofremoval.MakesureatonswitchisalignedwithatpartofD-shapedholeinelectronics
module(Figure13-9,Page13-8).TightenT ow/Runswitchboot/hexnut(1)to16in·lb(1.8N·m).
2.PlacetheTow/RunswitchintheTOWpositionandconnectthebatteries.SeeConnecttheBatteries–Electric
Vehiclesonpage1-5.
2020Precedent,Villager2and4MaintenanceandServiceManualPage13-7
