BrakeCableWHEELBRAKEASSEMBLIES
BRAKECABLEINSTALLATION
NOTE:Thedriver-sideandpassenger-sidebrakecablesarenotinterchangeable.Thedriver-sidecableisshorter
thanthepassenger-sidecable.Makesurethecorrectcableisusedonthecorrectside.
Besuretoorientthecablesothattheclevisendgoestothewheelratherthantotheequalizerbracket.
1.Inserttheendofthenewbrakecablethroughtheholeintheframe(Figure6-29).Pushonthecablehousingso
theclipsonthehousingendssecurethehousinginthehole.
650C
Figure6-29CableThroughFrame
2.Holdthebrakeactuatorrod(1)andtheequalizerbracket(2)intheuprightpositionandslipthecablehead
throughtheholeontopofthebracket.Pivottheequalizertothehorizontalpositiontocapturethecable
headsintheequalizer.
1
636D
Figure6-30InstallCablesInEqualizerBracket
Page6-202020Precedent,Villager2and4MaintenanceandServiceManual

Club Car Precedent Specifications

General

Power Source	Electric
Batteries	Six 8-volt (Electric)
Brakes	Mechanical Drum
Seating Capacity	2
Overall Length	91.5 in
Overall Width	47 in
Range	Up to 30 miles (depending on conditions)
Frame	Aluminum
Suspension	Leaf spring (front and rear)
Tires	18 x 8.5-8
Payload Capacity	800 lb
