Club Car Precedent Maintenance And Service Manual

REARSUSPENSIONLeafSprings(Two-Passenger)
9
LEAFSPRINGS(TWO-PASSENGER)
LEAFSPRINGREMOVAL(TWO-PASSENGER)
WARNING
•Liftonlyoneendofthevehicleatatime.Useasuitableliftingdevice(chainhoistorhydraulicoor
jack)with1000lb.(454kg)minimumliftingcapacity.Donotuseliftingdevicetoholdvehicleinraised
position.Useapprovedjackstandsofproperweightcapacitytosupportthevehicleandchock
thewheelsthatremainontheoor.Whennotperformingatestorserviceprocedurethatrequires
movementofthewheels,lockthebrakes.
1.Disablethevehicle.
2.ElectricVehicle:Disconnectthebatteriesanddischargethecontroller.
GasolineVehicle:Disconnectthebatteryandsparkplugwire.
3.Lifttherearofthevehicle.
4.Putaoorjackunderthetransaxledifferentialcasingtosupport,butnotlift,thedrivetrain.Raiseitjustenoughto
relievetensionontheshockabsorberswithoutcompressingthem.
5.Removethetireandwheelassemblyonthesidefromwhichthespringistoberemoved.
6.Removethebowtielockingpin(1)andtheclevispin(2)(Figure9-5).
651G
Figure9-5ConnectBrakeCable
7.Removethecableend(3)fromthebrakelever.
8.Removethebrakecablefromtheshockmountbracket(4).
2020Precedent,Villager2and4MaintenanceandServiceManualPage9-5
