Club Car Precedent Maintenance And Service Manual

GASOLINEVEHICLE-ELECTRICAL
COMPONENTSStarter/Generator
19
A
B B
A
1
1
1
1
A
1
A
2
1
1.Measureeachpositionintwoplaces,90degreesapart
496
Figure19-10InspectCommutator
ARMATUREGROUNDTEST
CAUTION
•Donotsubmergearmatureinsolvent.
NOTE:Beforetesting,wipethearmaturewithacleanclothandremovecarbondustandmetalparticlesfrombetween
commutatorbars.
Usingamultimeterseton200ohms,placethepositive(+)probeonthecommutatorbarsandthenegative(–)probe
onthearmaturecore.Thereadingshouldbenocontinuity.Ifthereadingisincorrect,replacethearmatureandthe
twobearings(Figure19-11,Page19-12).
2020Precedent,Villager2and4MaintenanceandServiceManualPage19-11
