Club Car Precedent Maintenance And Service Manual

WHEELBRAKEASSEMBLIESBrakeShoeRemoval
6
NOTE:Whenservicingvehicleswithseverelywornbrakeshoesandwhenthedrumscannotberemovedbynormal
methods,usethefollowingstepstominimizedamagetothebrakeclusterandbrakecomponents.
12.1.Inserta1/2inchx5/8inchcoldchisel(8)underthehead(9)ofeachpinandshearthemoffasillustrated
(Figure6-3).
NOTE:Thiswillreleasetheshoesfromthebackingplate,allowingthemtopivotawayfromtheinsideofthebrake
drum(10),whichshouldthenallowthebrakedrumtobepulledfree.
NOTE:Itmaybenecessarytoremovethesealantmaterialaroundtheheadofeachpin.
1400-18100-10220C
Figure6-3ShoeRetainerPins
13.Graspbothbrakeshoesandpullthem,togetherwiththesprings,outofthebrakeassembly(Figure6-4).
1400-17700-10225
Figure6-4RemoveBrakeShoes
2020Precedent,Villager2and4MaintenanceandServiceManualPage6-3
