Club Car Precedent Maintenance And Service Manual

19
Solenoid
GASOLINEVEHICLE-ELECTRICAL
COMPONENTS
7.1.Tightennutonbelttensiontool1/2turnandcheckbelttensionwithgauge(Figure19-15,Page19-16).
NOTE:Topreventerrorsinmeasurementcausedbyresidualtension,ensuretoloosen,thenreapply,theUniversal
BeltTensiongaugebetweenmeasurements.
7.2.Continuetotightenin1/2turnincrementsuntilproperbelttensionisachieved.
–Propertensionforausedstarter/generatorbeltis75to85lbf(334to378N).
–Propertensionforanewstarter/generatorbeltis120to130lbf(534to578N).
8.Seatthebelt.
8.1.Removeallothertools.
8.2.Thebelttensiontoolcanbetemporarilyleftinplace.
8.3.Connectbatteryonly.DONOTCONNECTSPARKPLUGWIRE.SeeConnecttheBattery-Gasoline
Vehiclesonpage1-4.SeefollowingWARNING.
WARNING
•Removeprybarbeforestartingengine.
•EnsureclearancebetweenF2terminalandstarter/generatorbracketbeforestartingengine.
8.4.Engagestarterandcrankengineaminimumof5secondsandamaximumof15secondstofullyseat
thebeltintopulleysandhelpeliminateanyslack.
9.Repeatstep7.
10.Maintaintensionandtightenadjustmentnut(4)to15to18lb·ft(20to24.5N·m).Tightenhexnuts(7)to20to
25lb·ft(27to34N·m)(Figure19-13,Page19-15).
11.Removebelttensiontool.
12.Conrmproperbelttensionwithanalmeasurement.
13.Connectsparkplugwire.
SOLENOID
SeeGeneralWarningsonpage1-2.
SOLENOIDREMOVAL
1.Disconnectthebatteryandsparkplugwire.
2.Removethenuts(1)fromeachpost(Figure19-18,Page19-19).
Page19-182020Precedent,Villager2and4MaintenanceandServiceManual

Club Car Precedent Specifications

General

Power Source	Electric
Batteries	Six 8-volt (Electric)
Brakes	Mechanical Drum
Seating Capacity	2
Overall Length	91.5 in
Overall Width	47 in
Range	Up to 30 miles (depending on conditions)
Frame	Aluminum
Suspension	Leaf spring (front and rear)
Tires	18 x 8.5-8
Payload Capacity	800 lb
