Club Car Precedent Maintenance And Service Manual

11
MonitorMenuCONTROLLERDIAGNOSTICTOOL(CDT)
PASSWORDTRIES(OEMACCESSLEVELONLY)
Apasswordisrequiredtoplacethevehiclein“privatespeedmode”(speedsetting4).Thespeedcontrollerwilllog
unsuccessfulandunauthorizedattemptstoplacethespeedcontrollerin“privatespeedmode”.Ifrepeatedattempts
areunsuccessful,thespeedcontrollerwillpermanentlylockoutaccessto“privatespeedmode”.Intheeventthat
“privatespeedmode”islockedout,thecontrollermustberemovedandshippedtoClubCarbeforeitcaneverbe
placedin“privatespeedmode”.SeeCodeA,CodeB,andCodeConpage11-8.
ODOMETER
Displaysapproximatedistancetravelledinmiles.
BDIINFO
LoadLineSOC
LoadLineSOCisthestateofchargeestimationbaseduponbatteryvoltageduringadeneddischargecurrent
(between50and60amps).
LoadLineValid
LoadLineValidisanindication(LoadLineValid=1)thatthedischargecurrentisbetween50and60amps.
BDIIntFactor
BDIIntFactorisanauto-adjustingcorrectionfactorforestimatingstateofchargebaseduponthedifferencebetween
thecurrentlyestimatedstateofchargeandtheLoadLineSOC.
OpenCircuitVoltageStart
OpenCircuitVoltageStartisthevoltage,asdeterminedbythecontroller,followingacycleoftheRun/Towswitchor
comingoutofsleepmode.
OpenCircuitSOCStart
OpenCircuitSOCStartistheestimatedstateofchargefollowingacycleoftheRun/T owswitchorcomingoutof
sleepmode.
BATTERYMONITOR
Thesemenuitemsreseteverytimethevehicleischarged.
LowestBatteryVoltage
Displaysthelowestbatterypackvoltagereachedsincethelastcharge.
IBattatLowestVolts
Displaysthecurrentthroughthecontrolleratthelowestbatterypackvoltage.
HighestBatteryVoltage
Displaysthehighestbatterypackvoltageafterbeingcharged.
CHARGINGTOTALS
Thesemenuitemsaccumulatetotalsforthelifeofthevehicle.
CompletedCharges
Displaysthenumberofcompletedchargecycles.
InterruptedCharges
Displaysthenumberofinterruptedchargecycles.
StorageCharges
Displaysthenumberofstoragechargecycles.
Page11-122020Precedent,Villager2and4MaintenanceandServiceManual

Club Car Precedent Specifications

General

Power Source	Electric
Batteries	Six 8-volt (Electric)
Brakes	Mechanical Drum
Seating Capacity	2
Overall Length	91.5 in
Overall Width	47 in
Range	Up to 30 miles (depending on conditions)
Frame	Aluminum
Suspension	Leaf spring (front and rear)
Tires	18 x 8.5-8
Payload Capacity	800 lb
