Club Car Precedent Maintenance And Service Manual

15
ACPowerConnectionELECTRICVEHICLE-BATTERYCHARGER
1
2
1.ACCord2.WireTie
2758
Figure15-5ACCordDrip-LoopExample
ACPOWERCONNECTION
WARNING
•InstallsurgearrestorsonincomingACpowerlines.Surgearrestorswillhelpprotectelectrical
componentsinthechargerandonthevehiclefromallbutdirectorcloselightningstrikes.
•Twohigh-frequencychargerscanshareacircuit,whichshouldbeadedicated15or20ampere
separatelyprotected(circuitbreakerorfuse)single-phasebranchcircuitthatcomplieswithall
applicableelectricalcodesforthelocation.
•ConnectthechargerACsupplycordtoaproperlygrounded,three-wireoutletwithinthevoltageand
frequencyrangeshownonthecharger.
•Donotuseanadaptertoplugthechargerwithathree-prongplugintoatwo-prongoutlet.Improper
connectionoftheequipment-groundingconductorcanresultinareoranelectricalshock.
•Placeallcordssotheywillnotbesteppedon,trippedover,orotherwisesubjectedtodamageorstress.
NOTE:MakesurethattheACcordprovidedwithyourchargerhastheproperACplugforyourlocation.Ifitdoesnot,
contactyourClubCarrepresentativetoobtainthepropercordorplug.
Page15-82020Precedent,Villager2and4MaintenanceandServiceManual
