F.20 Part. no. 8000 H1489 (10-2009)

ENGINE DISASSEMBLY

Clutch disassembly

- Remove the six retaining screws (2) and the clutch cover (3).

- Using an 8 mm wrench, unscrew the six screws (4) securing the clutch springs.

Remove springs, pressure plate (5) with bearing (6) and clutch actuator plate

(7).
