A: to increase clearance
B: to decrease clearance
Front brake lever adjustment and uid level check
The adjuster (1) located on the control lever, allows adjusting of the free play
(a). Free play (a) must be at least 3 mm.
The level of the uid in master cylinder reservoir must never be below the mini-
mum value (2), which can be checked from the inspection window on the rear of
the master cylinder body. A decrease of the uid level will let air into the system,
hence an extension of the lever stroke.
If the brake lever feels mushy when pulled, there may be air in the brake
line or the brake may be defective: CHECK THE BRAKING SYSTEM
(see Section "L").
Too much brake lever free play may reduce braking action: CHECK
BRAKE PAD THICKNESS (see Section "L").
Do not spill brake uid onto any painted surface or lens (for example
lights lens).
Do not mix two brands of uid. Completely change the brake uid in the
brake system if you wish to switch to another uid brand.
Brake uid may cause irritation. Avoid contact with skin or eyes. In case
of contact, ush thoroughly with water and call a doctor if your eyes were
exposed.
