Tightening torque gures
LUBRICATION POINTS-NOTES LUBRICANT-INSTALLATION INSTRUCTIONS
F Use sealant "AREXONS RHODORSEAL 5552" on installation
G WATER RESISTANT grease
O Engine oil
36 Special anged screw L.23.4 8 Nm- 0.8 Kgm- 5.9 ft/lb
37 Special anged screw L.31.3 8 Nm- 0.8 Kgm- 5.9 ft/lb
38 M5 x 0.8 - L8 (+LOCTITE 243) 6 Nm- 0.6 Kgm- 4.43 ft/lb
39 M10 x 1.25 5 Nm- 0.5 Kgm- 3.69 ft/lb
40 M10 - L104.5 40 Nm- 4 Kgm- 29.5 ft/lb
41 M10 - L104.5 40 Nm- 4 Kgm- 29.5 ft/lb
42 M6 - L20 8 Nm- 0.8 Kgm- 5.9 ft/lb
43 M4 - L10 3 Nm- 0.3 Kgm- 2.21 ft/lb
44 M5 - L25 6 Nm- 0.6 Kgm- 4.43 ft/lb
45 M4 - L12 (+LOCTITE 243) 3 Nm- 0.3 Kgm- 2.21 ft/lb
46 M5 (+LOCTITE 270 or 272) 6 Nm- 0.6 Kgm- 4.43 ft/lb
47 M5 - L30 1 Nm- 0.6 Kgm- 0.74 ft/lb
