D.13

SETTINGS AND ADJUSTMENTS

Part. N. 8000 H1489 (10-2009)

Rear brake pedal position adjustment

The position of the rear brake pedal with respect to the footrest may be adjusted

according to individual needs.

For adjusting, proceed as follows:

- Loosen the screw (1).

- Turn the cam (2) in order to raise or lower the brake pedal within the range

available (A).

- When nished, tighten the screw (1).

Once this adjustment is completed, adjust the free play of the pedal following the

instructions provided in paragraph "Rear brake pedal free play adjustment".

Husqvarna TE 250 2010 Repair Manual
