Tightening torque gures
1: 142.1 Nm, 14.5 Kgm, 104.8 ft/lb
Removing the rear wheel
Set a stand or a block under the engine and see that the rear wheel is lifted
from the ground.
Unscrew the nut (1) of the wheel axle (3) and extract it. It is not necessary to
loosen the chain tensioners (2); in this way, the chain tension will remain un-
changed after reassembly. Extract the complete rear wheel, keeping the spacers
located at the hub sides. To reassemble, reverse the
above procedure remembering to insert the brake disc into the calliper.
Do not operate the rear brake pedal when the wheel has been re-
moved; this causes the calliper pistons to move outwards.
After removal, lay down the wheel with brake disc on top.
After reassembly, depress the brake pedal until the pads are against
the brake disc.
