O.3Part. N. 8000 H1489 (10-2009)

“KIT” INSTALLATION INSTRUCTIONS

Carburettor KIT (TC)

- Remove the breather hose (1) from the steering stem.

- Turn the ring nut of the fuel cock (2) counter clockwise to shut off fuel supply

and loosen the clamp (3) on the hose running to the carburettor. Detach the

hose at carburettor end and let fuel drain into a pan.

- Remove the fuel tank retaining screw (4), push the front end of the scoops

slightly upwards and release them from the spoilers on the radiators.

- Remove the fuel tank together with the scoops.
