Radiator removal
- Remove the fuel tank together with scoops and spoilers as outlined in the
relevant paragraphs.
- Remove the electric cooling fan (TE – TXC) as described in the relevant
paragraph.
- Place a pan under the hose (1) to collect coolant, then loosen the clamp (2),
detach the hose (1) and drain all coolant.
- Loosen the clamp (3) and disconnect the hose (4) from the left-hand radiator
(5).
- Loosen the clamp (6) and disconnect the hose (7) from the right-hand radiator
(8).
- Remove the plastic grids (9) from the radiators.
- Remove the clamp (10) and disconnect the radiator connecting hose (11).
