Husqvarna TE 250 2010 Repair Manual

F.34 Part. no. 8000 H1489 (10-2009)
ENGINE DISASSEMBLY
Crankcase disassembly
- Remove the nine screws (1) from the left crankcase (2) (8 mm wrench).
Important: the screws (1) are not all the same length. Refer to gure
"A" on assembly to ensure correct installation.
FIG. "A"
a1= 6x60 mm
a2= 6x55 mm
a3= 6x70 mm
a4= 6x90 mm
