Husqvarna TE 250 2010 Repair Manual

H.53Part. N. 8000 H1489 (10-2009)
ENGINE REASSEMBLY
Starter motor seat cover installation (TC)
Ret the cover (1) with its gasket making sure the arrow is pointing "UP".
Tighten the screws (2) with the wire clip (3) placed on the upper screw.
Cylinder head cover, spark plug, oil feed hose installation
Position the central seal (1).
Fit the head cover (3) with its gasket to the head (2).
Tighten the screws (4) and (4a) (8 Nm, 0.8 Kgm, 5.9 ft/lb).
Screw 4 - L=23.4 mm
Screw 4a - L=31.3 mm
Install the spark plug (10-12 Nm, 1-1.23 Kgm, 7.2 -8.9 ft/lb).
