M.28

A Giallo

B Nero

Part. N. 8000 H1489 (10-2009)

ELECTRICAL SYSTEM

Carburettor throttle position sensor inspection

(TPS: Throttle Position Sensor) (TC)

Set the meter to the “Ohm” scale and disconnect the carburettor sensor connec-

tor (1) from the main wiring harness. Connect the meter probes to the terminals

of the YELLOW (A) and BLACK (B) wires and check that your readings match

the values given in the table.

a throttle twistgrip CLOSED 890-990

b throttle twistgrip

FULLY OPEN

"KEIHIN“ MX 37- MX 41 3.4-4.4 K +/- 5%
