M.41Part. N. 8000 H1489 (10-2009)
ELECTRICAL SYSTEM
• Control unit connection (TC)
Connect the control unit connector (4) as shown.
• Ignition coil connection (TC)
Connect the ignition coil connectors (5) as shown.
• Gear sensor cable connection (TC)
Connect the gear sensor connector (6) as shown.
