Throttle cable adjustment (TE - TXC)
To check the correct adjustment of the throttle cable, operate as follows:
- Loosen the screw and remove the cover (1).
- Make sure the cables protrude by 10 mm (length A). If they need adjusting,
loosen the check nuts (2) and turn the adjuster screws (3).
When nished, tighten the check nuts (2).
- Always check length "A" after replacing the cables (4) and (5).
- Ret the cover (1) and tighten the screw.
Operation with damaged throttle cable could result in an unsafe riding
condition.
Exhaust gas contains poisonous carbon monoxide. Never run the engine
indoors.
To replace the cables, you will need to remove the fuel tank as described in the
relevant paragraph.
Enrichener lever play adjustment (TE - TXC)
The lever (1) holder features an adjuster screw (2) to adjust free play. Free play
should be about 3 mm: if not so, loosen the check nut and turn the adjuster screw
as required (loosen to decrease play or tighten to increase it).
