Tightening torque gures
LUBRICATION POINTS-NOTES LUBRICANT-INSTALLATION INSTRUCTIONS
O Engine oil
O/G Engine oil or WATER RESISTANT grease
C Join crankcase halves using Loctite 5205
19 M5 - L12 (+LOCTITE 270 or 272) 6 Nm- 0.6 Kgm- 4.43 ft/lb
26 M8 X 1.25 (Al) 8 Nm- 0.8 Kgm- 5.9 ft/lb
27 M5 - L16 8 Nm- 0.8 Kgm- 5.9 ft/lb
28 M5 x 0.8 - L20 6 Nm- 0.6 Kgm- 4.43 ft/lb
29 M6 x 1 (+LOCTITE 243) 8 Nm- 0.8 Kgm- 5.9 ft/lb
30 M8 x 1.25 (+LOCTITE Alt. 272) 25 Nm- 2.55 Kgm- 18.44 ft/lb
31 M6 - L14 (+LOCTITE Alt. 272) 8 Nm- 0.8 Kgm- 5.9 ft/lb
32 M6 - L10 (+LOCTITE Alt. 243) 8 Nm- 0.8 Kgm- 5.9 ft/lb
40 M6 - L20 8 Nm- 0.8 Kgm- 5.9 ft/lb
