Tail light replacement
Remove the tail light as follows:
- Loosen the two screws (1) under the rear mudguard.
- Extract the tail light (2) and disconnect the connector (3).
Once the tail light has been replaced, reverse the above procedure to reas-
semble.
Be careful not to overtighten the screws.
Number plate bulb replacement
- Loosen screw (1) and remove the number plate bulb (2) from the mudguard.
- Extract the bulb holder (3) with the bulb (4) from the housing.
- Pull the bulb (4) to detach it from bulb holder.
Once the tail light has been replaced, reverse the above procedure to reas-
semble.
