Husqvarna TE 250 2010 Repair Manual

M.48 Part. N. 8000 H1489 (10-2009)
ELECTRICAL SYSTEM
• Fuelpumpconnectorposition(TE-TXC)
Position the fuel pump connector (21) as shown.
• MAQSconnector(TE-TXC)
Connect the connector (22) as shown.
• Enginewatertemperatureconnector
 (TE-TXC)
Connect the engine water temperature connectors (23) to the
thermostat.
• Lambdasensorpositionandconnector
 (TE-TXC)
Tighten the Lambda sensor (24) in the corresponding seat.
Connect the Lambda sensor connector (25) as shown.
