Husqvarna TE 250 2010 Repair Manual

F.23Part. no. 8000 H1489 (10-2009)
ENGINE DISASSEMBLY
Slider removal
- Use a 5 mm Allen wrench to loosen the screw (1) and remove the slider
(2).
Kick start disassembly
- Release the spring (1) from the casing (2) and remove the complete shaft
assembly (3). Be careful not to lose the washer (11) located on the crank-
case.
