7.4 - 22
COMBIVERT
F5-A, -E, -H
© KEB, 2012-10
Setpoint, rotation- and ramp setting
7.4.8.5
Time factor acceleration/deceleration (oP
.62
)
The time factor extends the standard ramp time (oP
.28...31) by the adjusted value.
The s-curve times do not change.
oP
.62: Time factor acceleration/deceleration
V
alue
Description
0: off
The linear ramp times are extended by the adjusted factor
.
1: double
2: 4-fold
3: 8-fold
4: 16-fold
5: 0,1-fold
161
163
