Parameter sets
7.14.4 Indirect and direct set-addressing
At indirect set-addressing the parameter values are displayed and edited based on the set indicator (Fr.09).
The direct set-addressing enables the display or writing of a parameter value independent of the set indicator
directly into one or several parameter sets. The direct set programming is only possible with bus operation.
7.14.5 Copying of parameter sets via keyboard (Fr.01)
0. Fr.1
1. Fr.1
2. Fr.1
3. Fr.1
4. Fr.1
5. Fr.1
6. Fr.1
7. Fr.1
▲
DOWN
UP
▼
Adjust target set
A
⇒
Fr
·
1
〉
with Func. to the source
〉
with Funct.
1
2
3
4
5
6
7
▲
DOWN
UP
▼
Adjust source set
0
dEF_S
ini_A
ini_S
dEF_A
With the keys UP/Down and at ashing
point the target set 0...7 is adjusted in
addition to the parameter set number.
The active (A) parameter set must not
be adjusted as target set while copying.
If the target set is > 0, only the program-
mable parameters are overwritten!
The source set is adjusted with the
keys UP/Down. The copying process
is started with „Enter“. Copying is only
possible with opened control release or
error, otherwise „I_oPE“ appears in the
display (invalid operation).
After copying „PASS“ appears in the dis-
play and could be erase by „ENTER“.
