KEB COMBIVERT F5-H User Manual

Page 7.5 - 12 COMBIVERT F5-A, -E, -H © KEB, 2012-10
Motor data and controller adjustments of the asynchronous motor
7.5.2.1.1 Motor rating plate data
Input of the motor rating plate data is at the beginning of each start-up:
- dr.00 TPIM rated current
- dr.01 TPIM rated speed
- dr.02 TPIM rated voltage
- dr.03 TPIM rated power
- dr.04 TPIM cos(phi)
dr.05 TPIM rated frequency
7.5.2.1.2 Motor adaption
After input of this data, the operator must switch to closed-loop operation (cS.00 = 4) and enter Fr.10 = 1 or 2
(explanation see below) once.
Fr.10 Reseteld-orientedcontrolparameter
Value Function
1: uF.09 (F5-M/ S) Precharging dependent on the voltage class of the inverter and/or the
value of uF.09
2: act. DC link voltage (F5-M/ S) precharging dependent on the current DC link voltage of the inverter
3: Start motor adaption (F5-G) only for open loop V/f-characteristic operation
The inverter must be in status "noP", i.e., the input "control release" (ST) may not be set. Thus the following
parameter are pre-charged dependent on the motor and inverter data:
Denition of the limiting characteristic:
- dr.16 TPIM Mmax at dr.18
- dr.17 TPIM speed for Mmax
- dr.18 TPIM Field weakening speed
Denition of magnetisation:
- dr.19 Flux adaption factor
- dr.20 Field weakening curve
Current controller
- dS.00 KP current
- dS.01 KI current
Torque limits:
- cS.19 abs. torque ref
- cS.20...cS.23 torque limit (clockwise rotation motor operation, counter clockwise rotation motor operati-
on, clockwise rotation generator operation, counter clockwise rotation generator operation)
- Pn.61 quick stop torque limit
