Speed measurement
© KEB, 2012-10 COMBIVERT F5-A, -E, -H Page 7.11 - 3
7
7.11
Speed measurement
7.11.1 Designs
The KEB COMBIVERT F5 supports two from each other separated encoder channels. Each encoder channel
can support following interface dependent on the available hardware:
Encoder channel 1 (X3A)
• is a 15pole incremental encoder input for rectangular signals
Encoder channel 2 (X3B) can support following interfaces
• 9pole incremental encoder input for rectangular signals
• Incremental encoder output
• Incremental encoder in-/output
Further Interfaces (describes in separate manuals)
• Synchronous serial interface (SSI)
• Tachometer input
• Initiator input
• Hiperface
• Endat
• SinCos
7.11.1 Encoder interfaces


X3A
X3B
Die Kondensatorentl
zeit betrÌgt 5 min.!
Ein Fehlerstromschu
schalter ist als allei
SchutzmaBnahme ni
zulÌssig!
Warnung:
X3A
X3B
