Page 7.15 - 22 COMBIVERT F5-A, -E, -H © KEB, 2012-10
Special functions
The diameter signal of 0% corresponds to the minimum diameter of the reel bale (dmin).
The output speed of the ramp generator (ru.02) is not changed in this case.
A diameter signal of 100% corresponds to the maximum diameter of the reel bale (dmax).
The ratio of minimum to maximum diameter (dmin/dmax) must be known in order to be able to calculate the
required speed change.
The ratio of minimum to maximum diameter (dmin/dmax) is preset by way of oP.49 and can be adjusted within
the range of 0,010...0,990 with a resolution of 0,001.
The corrected output speed of the ramp generator is determined as follows:
fn_Ramp
fn_Setting: = –––––––––––––––
1+DS • (1/oP.49-1)
fn_Ramp: Output frequency/speed of ramp generator
fn_presetting: Corrected output frequency/speed
DS:
Diameter signal 0…100 % (0…1)
oP.49: (d
min
/d
max
)
Rate of change of the diameter signal
The rate of change of the diameter signal can be limited by a ramp generator.
Parameter oP.46 „ext. funct. acc/dec time“ denes a time within the range of 0.00...20.00 s, which is required
for a change of the diameter signal of 0...100%.
7.15.8 Analog setting of parameter values
With this function it is possible to preset parameter values analog. The AUX-function or the motor-poti function
can be adjusted as source.
Analog parameter setting source (An.53)
This parameter determines whether the analog parameter setting occurs via the motor-poti or the aux-function.
An.53: Analog parameter setting source
Value Function
0 AUX
1 Motorpoti function
The bus address of the parameter, that is to be adjusted in analog mode, is adjusted here (see chapter 11.1).
Following parameters can be adjusted.
Analog parameter setting destination (An.54)
uF.01 / 07
cn. 04 / 05 / 06
An.32 / 37 / 42 / 48
LE.00 / 01 / 02 / 03 / 04 / 05 / 06 / 07
cS.06 / 09 / 19 / 20 / 21 / 22 / 23
Ec.04 / 14
PS.31 / 33
