KEB COMBIVERT F5-H User Manual

Page 7.11 - 10 COMBIVERT F5-A, -E, -H © KEB, 2012-10
Speed measurement
7.11.6 Encoderidentier
Before start-up the inverter must be adjusted to the used encoder.
Encoder interface 1 / 2 (Ec.00, Ec.10)
Ec.00 displays the installed encoder interface 1; Ec.10 displays theencoder interface 2. The values correspond
to following interfaces:
Ec.00, Ec.10: Encoder interface 1/ 2
Value Description
0 no
1 TTL-Incremental encoder input
2 Incremental encoder
output 5 V TTL
3 Incremental encoder input and output direct
(non-divisible with Ec.27; switchable in- output with Ec.20)
4 Incremental encoder input and output TTL (switchable with Ec.20)
5 Initiator
6 Synchronous serial interface (SSI)
7 Resolver
8 Tacho
9 Incremental encoder output TTL (from resolver over channel 2)
10 Incremental encoder output TTL
11 Hiperface
12 Incremental encoder
input 24 V HTL
13 Incremental encoder input TTL with error detection
14 SinCos encoder input
15 Incremental encoder
input 24 V HTL with error detection (push-pull)
16 ENDAT
17 Incremental encoder
input 24 V HTL with error detection
18 Analog option ±10 V
19 Reslover
20 SSI sincos
21 Overspeed limiter
22 UVW-Interface
23 Inc. emulation 10-30V
24 Inc. emulation 10-30V
25 Overspeed limiter HTL
26 Incremental encoder input TTL with error detection 5V supply terminal
27 Incremental encoder input HTL-push-pull terminal block with error detection
28 Endat/BiSS (switchable with Ec.62)
29 Incremental encoder output TTL variable
30 Position via Ec.28
In case of an invalid encoder identication, error „E.Hyb“ is indicated and the measured value is displayed
inverted in Ec.00/Ec.10.
On changing the encoder interface the error „E.HybC“ is indicated. The change is conrmed by writing on pa-
rameter Ec.00 or Ec.10 and the default values for the new interface are loaded. From version 4.2 the message
is acknowledged with error reset (terminal ST or RST).
