KEB COMBIVERT F5-H User Manual

Start-up
© KEB, 2012-10 COMBIVERT F5-A, -E, -H Page 6.2 - 11
6
12. Enterapplicationspecicdata
Application specifc data are e.g.
• limit values (speec limits, torque limits etc.)
⇒ oP Parameter (chapter 7.4 Setpoint limits)
⇒ cS Parameter (chapter 7.8 torque display and limitation)
• acceleration / deceleration ramps
⇒ oP Parameter (chapter 7.4 Ramp generator)
• Function of the digital in- / outputs
⇒ di Parameter (chapter 7.3 Digital in- and outputs)
• type of speed setpoint setting
⇒ oP Parameter (chapter 7.4) etc.
Proper data for the adaption of the inver-
ter to the respective application can be
nd in the corresponding chapters.
13. Adjust speed controller
The speed controller parameters can be calculated by the
inverter for applications with constant inertia and rigidly cou-
pled load (see chapter 7.7)
The speed controller must be manually adapted if this ad-
justment is not workable for the application or if the result is
nonsatisfying.
The maximum voltage controller must be parameterized if
the eld weakening range is used.
Note:
Current and ux controller are automatically adjusted during
identication.
14. Test run
Check whether the drive operates stable in all speed ranges
and under load conditions.
If error messages occur during the start-up phase, read chapter 8 „Fault diagnosis“.
6.2.1.4 Start-up F5H-M (ASCL/ vector-controlled without encoder feedback with motor model)
Attention: The motor temperature sensor must be connected.
1. Open control release
deactivate terminal X2A.16
⇒ inverter state ru.00 = „noP“/„0: no control release“
