BeneVision N1 Patient Monitor Operator’s Manual 15 - 1
15 Review
15.1 Review Overview
Trends are patient data collected over time and displayed in graphic, tabular, or other forms to give you a picture
of how the patient's condition is developing. You can review the trend data in the
Review dialog, Minitrends
screen, or OxyCRG screen (Minitrends screen and OxyCRG screen are only available when the N1 is used with the
independent external display). The
Review dialog also enables access to review the events, 12-lead ECG analysis
results and waveforms, full disclosure waveforms, and so on.
15.2 Review Dialog
The Review dialog contains tabs to display trend data in tabular, graphic, or other forms.
15.2.1 Accessing the Review Dialog
To enter the review dialog, select the Main Menu quick key → from the Review column select the desired
option.
15.2.2 Example Review Dialog
The review pages have a common structure. The graphic trends review page is taken as an example:
(5)
(7)
(6)
(1)
(2)
(3)
(4)
(8)
(9)
(1) Event type indicator: different color blocks match different types of events:
■ Red: high priority alarm event
■ Yellow: medium priority alarm event
■ Cyan: low priority alarm event
■ Green: manual event
■ White: operation-related event
(2) Current screen time line: indicates the time length of the current screen.
(3) Waveform area: displays trend curves. The color of trend curves is consistent with the color of parameter labels.
