BeneVision N1 Patient Monitor Operator’s Manual A - 9
■ The delay for monitor-related settings configured at the CMS to be effective: ≤ 2 seconds.
■ The total delay of data transmission from one monitor to the other: ≤ 2 seconds.
■ The delay for the monitor to reset alarms of another to be effective: ≤ 2 seconds.
A.13.2.3 Wi-Fi Network Stability
The ratio of the communication data loss on the CMS from any monitor does not exceed 0.1% over a 24-hour
period (12 of the 16 monitors connected to the network roam for 30 times).
Testing conditions are as follows:
■ Number of the monitors supported by a single AP: ≤ 16.
■ Each monitor can communicate with the CMS.
■ Two monitors are used to view other monitors.
■ Only one monitor can transmit history data.
■ The weakest strength of the AP signal where the monitor is located cannot be less than -65 dBm.
A.13.2.4 Line of Sight Distance
The line of sight distance between the monitor and the AP is no less than 50 meters.
A.14 Measurement Specifications
The adjustable range of alarm limits is the same with the measurement range of signals unless otherwise
specified.
A.14.1 ECG Specifications
ECG
Standards Meets the requirements of IEC 60601-2-27: 2011 and IEC 60601-2-25: 2011
Lead set 3-lead: I, II, III
5-lead: I, II, III, aVR, aVL, aVF, V
6-lead: I, II, III, aVR, aVL, aVF, Va, Vb
12-lead: I, II, III, aVR, aVL, aVF, V1 to V6
ECG standard AHA, IEC
Display sensitivity 1.25 mm/mV (X0.125), 2.5 mm/mV (X0.25), 5 mm/mV (X0.5), 10 mm/mV (X1),
20 mm/mV (X2), 40 mm/mV (X4), Auto, less than ±5% error
Sweep speed 6.25 mm/s, 12.5 mm/s, 25 mm/s, 50 mm/s, less than ±5% error
Bandwidth (-3dB) Diagnostic mode:
Monitor mode:
Surgery mode:
ST mode:
High Freq Cut-off (for 12-lead
ECG analysis):
0.05 to 150 Hz
0.5 to 40 Hz
1 to 20 Hz
0.05 to 40 Hz
350 Hz (0.05 to 350 Hz), 150 Hz (0.05 to 150
Hz), 35 Hz (0.05 to 35 Hz), 20 Hz (0.05 to 20
Hz) selectable.
Common mode rejection ratio Diagnostic mode, monitor mode, surgery mode, ST mode, High Freq Cut-off:
>90 dB (with notch filter off)
Monitor mode, surgery mode, ST mode: >105 dB (with notch filter on)
Notch filter 50/60 Hz
Monitor, surgical, and ST mode: notch filter turns on automatically
Diagnostic mode and High Freq Cut-off: notch filter is turned on/off manually
Differential input impedance ≥5 MΩ
Input signal range ±8 mV (peak-to-peak value)
