BeneVision N1 Patient Monitor Operator’s Manual A - 1
A Product Specifications
A.1 Monitor Safety Specifications
The monitor is classified, according to IEC 60601-1: 2005.
A.2 Physical Specifications
Degree of protection against electrical
shock
Type CF defibrillation proof for ECG, RESP, TEMP, IBP, SpO
2,
and NIBP
Type BF defibrillation proof for CO
2
Type of protection against electrical
shock
Class I
Ingress Protection N1 monitor: IP44 (protected against ingress of foreign objects no less than 1.0
mm, and against access to hazardous parts with wire; protect against harmful
effects of splashing water)
Dock/Modular Rack/AC Adapter: IPX1 (protected against harmful effects of
vertically falling water drops)
Transport Dock: IP22 (protected against ingress of foreign objects no less than
12.5 mm and against access to hazardous parts with finger; protected against
harmful effects of vertically falling water drops with the device tilted at any
angle up to 15°)
Degree of safety of application in the
presence of flammable anesthetic
mixture with air or with oxygen or
nitrous oxide
The equipment is not suitable for use in the presence of a flammable
anesthetic mixture with air or with oxygen or nitrous oxide
Mode of operation Continuous
Item Maximum
Weight (kg)
W × H × D (mm) Comments
N1 main unit 0.95 148.5 × 103 × 81 without internal CO
2
module
N1 main unit 1.17 148.5 × 103 × 81 with internal CO
2
module
Modular Rack 0.60 165 ×130×168 /
Dock 0.97 190×125×155 /
Transport Dock 2.51 162.4×253×195.5 with cable box
Transport Dock 1.80 162.4×113×195.5 without cable box
Microstream CO
2
module 0.40 136.5 × 40 × 102 /
Sidestream CO
2
module 0.64 136.5 × 40 × 102 with O
2
Sidestream CO
2
module 0.52 136.5 × 40 × 102 without O
2
