A - 6 BeneVision N1 Patient Monitor Operator’s Manual
A.10 Signal Outputs Specifications
A.11 Data Storage
ECG Analog Output
Bandwidth
(-3dB; reference frequency: 10Hz)
Diagnostic mode: 0.05 to 150 Hz
Monitor mode: 0.5 to 40 Hz
Surgical mode: 1 to 20 Hz
ST mode: 0.05 to 40 Hz
Maximum QRS delay 25 ms (in diagnostic mode, and non-paced)
Gain (reference frequency 10Hz) 1V/mV (±5%)
Pace enhancement Signal amplitude: V
oh
≥2.5V
Pulse width: 10ms±5%
Signal rising and falling time: ≤100µs
IBP Analog Output
Bandwidth (-3dB; reference
frequency:1Hz)
0 to 40 Hz
Maximum transmission delay 30 ms
Gain (reference frequency 1Hz) 1 V/100 mmHg, ±5%
Defib Sync Pulse
Output impedance ≤100 ohm
Maximum time delay 35 ms (R-wave peak to leading edge of pulse)
Amplitude High level: 3.5 to 5 V, ±5%, providing a maximum of 10 mA output current;
Low level: < 0.5 V, receiving a maximum of 5 mA input current.
Pulse width 100 ms ±10%
maximum rising and falling time 1 ms
Video Output
Video signals VGA signal
Alarm output
Alarm delay time from the monitor to
remote equipment
The alarm delay time from the monitor to remote equipment is ≤2 seconds,
measured at the monitor signal output connector.
Alarm signal sound pressure level range 45 db(A) to 85 db(A) within a range of one meter
Trends A minimum of 120 hours trend data with the resolution no less than 1 minute.
Events 1000 events
NIBP measurements 1000 sets
Interpretation of resting 12-lead ECG
results
20 sets
Full-disclosure waveforms 48 hours at maximum. The specific storage time depends on the waveforms
stored and the number of stored waveforms.
OxyCRG view 48 hours. Trend data is stored one dot per second and the waveform stored is
a compressed waveform.
