15 - 2 BeneVision N1 Patient Monitor Operator’s Manual
15.2.3 Symbols on Review Pages
The following table lists the symbols on review pages.
15.2.4 Common Operations
This section describes common operations for all review pages.
15.2.4.1 Browsing Trend Data
Browse trend data in one of the following ways:
■ Move the cursor.
■ Move the slider .
■ Slide your finger on the screen.
15.2.4.2 Viewing Events
You can view the following types of events:
■ Manually triggered events
■ Parameter-related operation events and alarm-related events
■ Operation events not related to parameters, such as system time change
View events in either of the following ways:
■ Select and select the desired event.
■ Select or to jump to the previous event or next event.
Events are displayed in a chronological order. The most recent event is displayed at the top. The number of
asterisk symbols before an event indicates alarm priority as follows:
■ ***: high priority alarm
(4) Time line: indicates the entire time length.
■ : indicates the time length of reviewable trend data. can be moved within this time length.
■ : indicates the time length of no trend data. cannot be moved within this time length.
Different color blocks along the time line indicate events of different types. See the color definition for the event
type indicator.
(5) Event area: displays the event of the cursor time. Selecting the event accesses the event list. If there is no event at
the cursor time, the cursor time is displayed.
(6) Cursor: this is adjusted by touching different locations. Adjusting this changes the data displayed in the Event
area and Numeric area.
(7) Numeric area: displays numeric values at the cursor indicated time. The background color of numeric values
matches the alarm priority.
(8) Slider: indicates the position of current screen time in the entire time length. Dragging this button left or right
enables you to locate the trend data at a specific time and also refreshes trend data in current screen
accordingly.
(9) Button area.
Symbol Description
Slider: indicates the position of current screen time in the entire time length. Dragging
the slider left or right enables you to locate the trend data at a specific time and also
refreshes data in current screen accordingly.
or Goes to the previous or next event.
Event list: displays events in a chronological order. The most recent event is displayed
at the top. The number of asterisk symbols before an event indicates alarm priority.
Print button: select it to output patient information and data through the printer.
