15 - 8 BeneVision N1 Patient Monitor Operator’s Manual
■ From the OxyCRG screen, select Review.
15.2.9.2 Changing the Resolution of Trend Curves
To set the resolution of trend curves, follow this procedure:
1. Enter the OxyCRG review page.
2. Set
Zoom.
NOTE
• If the Zoom is set for a large duration (for example, 8 hrs), the screen may show "No Patient Data" for
the first several minutes of data collection (for example, 6 minutes), but data will be shown after
enough data has been collected.
15.2.9.3 Changing the Compressed Waveform
To set the compressed waveform options, follow this procedure:
1. Enter the OxyCRG review page.
2. Set
Waveform.
15.2.9.4 Printing an OxyCRG Review Report
To print an OxyCRG review report, follow this procedure:
1. Enter the OxyCRG review page.
2. Select to enter the
Print Setup dialog.
3. Select
Print. The report duration corresponds to the duration of data shown on the screen.
15.2.10 12-Lead ECG Review Page
When 12-lead ECG analysis is performed, you can review the most recent 20 events of 12-lead analysis. For more
information, see
8Resting 12-Lead ECG Analysis.
15.2.10.1 Entering the 12-Lead Review Page
Choose one of the following methods to enter the 12-lead ECG review page:
■ Upon completion of 12-lead ECG analysis, select Review from the 12-Lead Interpretation page. For more
information, see
8Resting 12-Lead ECG Analysis.
■ Select the Main Menu quick key → from the Review column select 12-Lead ECG.
15.2.10.2 Switching to Median Complex
The median complex template displays 12-lead ECG waveforms on one page in 4 columns, with 3 lines in each
column, and one rhythm lead waveform at the bottom. Additionally, a short vertical bar appears above each
waveform, marking the start and end positions of the P-wave and the QRS-wave and the end position of the T-
wave.
To view Median Complex, follow this procedure:
1. Enter the 12-lead review page.
2. Select
Median Complex.
3. Selecting
Waveform can return to the 12-lead ECG waveform page.
15.2.10.3 Setting 12-Lead ECG Waveforms
To set the 12-lead ECG waveforms on the review page, follow this procedure:
1. Enter the 12-lead review page.
2. Set
Speed, Gain, and Layout.
