3 - 4 BeneVision N1 Patient Monitor Operator’s Manual
When the touchscreen is locked, the quick key changes to . To unlock the touchscreen, touch anywhere
on the touchscreen and swipe the slider up as instructed.
NOTE
• Wipe off any water on the touchscreen in case of rain or water spray.
3.5.2 Using the On-Screen Keyboard
The on-screen keyboard enables information entry:
■ Enter the information by selecting one character after another.
■ Select the Backspace key to delete single characters or select to delete the entire entry.
■ Select the Caps Lock key to access uppercase letters.
■ Select the Enter key to confirm the entry and close the on-screen keyboard.
3.5.3 Using the Barcode Reader
The monitor supports both linear (1D) barcode reader and two-dimension (2D) barcode reader. The barcode
reader is connected to the monitor through the USB connector on the rear of the Dock.
NOTE
• Use the Mindray custom barcode reader to obtain all the available patient information from both
the 2D and 1D barcodes. Using other barcode readers can only output the patient’s medical record
number (MRN) and visit number.
3.5.3.1 Clearing Old Data Formats (for the Mindray Custom 2D Barcode Reader)
If using the Mindray custom 2D barcode reader (Model HS-1R or HS-1M), before using it for the first time, clear
old data formats and configure the barcode reader.To do so, follow this procedure:
1. Scan the engineering barcode to clear the previous data format.
2. Scan the 2D engineering barcode which contains your hospital’s data format.
NOTE
• Contact the scanner manufacturer or Mindray to obtain the engineering barcodes for clearing data
formats and programming the hospital’s data format.
