BeneVision N1 Patient Monitor Operator’s Manual 4 - 9
• The data presented in the Remote View screen has a delay. Do not rely on this screen for real time
data.
4.5.3 Adding a Bed
After adding the desired remote devices, then the alarms from these devices can be viewed on the monitor. To
add a remote device, follow this procedure:
1. Enter the Select Bed dialog. To do so, choose either of the following ways:
â—† In the Remote View screen, select Select Bed. For more information, see 4.5.1Entering the Remote
View Screen.
â—† Select the icon at the alarm watch tile if the tile is configured to display on the main screen.
2. In the Select Bed dialog, select a desired department. All the beds under this department will be listed.
3. Select a desired tile at the A-W1, A-W2 or A-W3 areas and then select a bed from the bed list. The selected
bed will appear in the tile.
• The added bed is indicated by a check mark (√) at the right of the bed list.
4.5.4 Removing a Bed
To remove a remote device from remote monitoring, follow this procedure:
1. Enter the Select Bed dialog. Choose either of the following ways:
â—† In the Remote View screen, select Select Bed. For more information, see 4.5.1Entering the Remote
View Screen.
â—† Select the icon in the alarm watch tile if the tile is configured to display on the main screen.
2. In the Select Bed dialog, select a bed at the A-W1or A-W2 area, and then select Clear Bed. If you want
remove all beds, select Clear All Beds.
4.5.5 Displaying the Main Bed
In the Remote View screen, you can select a bed in the alarm watch area, then the main body of the Remote
View screen will display the real time monitoring screen of the device.
â—† Each bed displays the room number, bed number, connection status and alarm status. The
background color indicates the alarm status on the corresponding bed.
Background Color Description
Green No alarm is occurring at the bed.
Red The remote device is disconnected or a high priority alarm is currently the highest
alarm level on the bed. If the remote device is disconnected, the icon is
displayed.
Yellow The medium priority alarm is currently the highest alarm level on the bed.
Cyan The low priority alarm is currently the highest alarm level on the bed.
Grey The bed is in the standby mode.
(2)
Main area
Displays the patient’s information, alarm status and messages, waveforms, measurements, etc. of the
selected bed. This bed is called main bed.
