5-5

Using Variables to Edit the Flow [TDM

Editor]

Using this Editor, more advanced editing of a flow can be done.

Click TDM Editor on the Tool shortcut menu to open the Edit flow screen.

5-5-1

Edit Flow Screen

In this screen, you can create, define, reference, and assign variables to be used in Measurement

flows and Scenes. You can also arrange, add, or delete processing units in a scene and perform test

measurements.

Refer to 5-1 What Is a Scene? on page 5 - 2.

Refer to 7-1 What Is a Scene Group? on page 7 - 2.

Structure of the Edit Flow Screen

The Edit flow screen is composed of three tabs: Edit flow, Scene variable, and System variable. Click

a tab to switch among screens.

Edit flow screen

Set in each processing item

Edit flow

Scene variable

System variable

Unit setting UI

For each screen, refer to the following.

• Edit flow (Edit Flow Tab Screen on page 5 - 15)

• Scene variable (Scene Variable Tab Screen on page 5 - 19)

• System variable (System Variable Tab Screen on page 5 - 22)

• Unit setting UI (Open the Unit Setting UI (Editing Dialog) on page 5 - 26)

5 Creating Measurement Scenes

5 - 14

FH/FHV Series Vision System User’s Manual (Z365-E1)
