4 Click ▼ on the right side of the scene name text box, and Select a scene including a unit to
reference.
The flow of the selected scene is displayed under the scene number.
5
Select a processing unit to add from the displayed flow.
6
Click Append icon or Insert icon at the upper side of the Unit added tab.
Additional Information
The following operation also enables processing items to be added to the Unit list (flow).
• Drag a processing unit selected on the processing item list and drop it on the Unit list (flow).
• Right-click a processing unit selected on the processing item list and click Append or Insert.
When clicking Insert, first select a position on the Unit list (flow) where the selected process-
ing unit will be inserted.
Precautions for Correct Use
When a processing unit is added from another scene, the system variables and parameters be-
ing used in the original scene are also added. Since the scene variables being used in the origi-
nal scene cannot be referenced across scenes, the definition and values cannot be copied. The
scene variable name used in the original scene is however displayed in the variable area for the
input parameter area and output parameter area on the Edit flow tab screen. Therefore, check
such undefined scene variables using the “Variable assignment list” window. Undefined scene
variables are displayed in red. Re-define or delete them.
The selected processing item is added to the bottom (Append) or the specified position (Insert)
on the Unit list (flow).
5-5-3
Editing Scenes [TDM Editor]
Here explains how to switch, copy, and delete scenes, or change the name of scenes.
Additional Information
Scene groups cannot be edited. For scene groups, perform it in the main screen.
For details, refer toSection 5 Creating Measurement Scenes on page 5 - 1.
Switching Scenes
1 Select Scene tab on the TDM editor.
A list of scenes is displayed. The current scene has a check mark.
5 Creating Measurement Scenes
5 - 33
FH/FHV Series Vision System User’s Manual (Z365-E1)
5-5 Using Variables to Edit the Flow [TDM Editor]
5
5-5-3 Editing Scenes [TDM Editor]
