Omron fh series User Manual

A-4-3
Compensate image
Processing item Support Processing item Suport
Position Compensation OK Stripes Removal Filter II OK
Filtering OK Polar Transformation OK
Background Suppression OK Trapezoidal Correction OK
Brightness Correct Filter OK Machine Simulator -
Color Gray Filter OK Image Subtraction OK
Extract Color Filter OK OK Advanced filter OK
Anti Color Shading OK Panorama -
A-4-4
Support measurement
Processing item Support Processing item Suport
Unit Macro - Parallelize OK
Unit Calculation Macro - Parallelize Task OK
Calculation OK Statistics OK
Line Regression OK Calibration Data Reference OK
Circle Regression OK Position Data Calculation OK
Precise Calibration OK Stage Data OK
User Data - Robot Data OK
Set Unit Data - Vision Master Calibration OK
Get Unit Data - PLC Master Calibration -
Set Unit Figure - Transfer Position Data OK
Get Unit Figure - Calc Axis Move OK
Trend Monitor OK Calc Axis Move by Multipoint OK
Image Logging OK Detection Point -
Image Conversion Logging OK Manual Position Setting -
Data Logging - Camera Calibration OK
Elapsed Time OK Data Save -
Wait OK Conveyor Calibration -
Focus - Scene OK
Iris - System information OK
A-4-5
Branch
Processing item Support Processing item Suport
Conditional Branch - Selective Branch -
End OK Conditional execution (If) OK
DI Branch - Conditional execution (Else) OK
Control Flow Normal - Loop OK
Control Flow PLC Link - Loop suspension OK
Control Flow Parallel - Select execution (Select) OK
Control Flow Fieldbus - Select execution (Case) OK
Appendices
A - 9
FH/FHV Series Vision System User’s Manual (Z365-E1)
A-4 FHV series Processing items
A
A-4-3 Compensate image

Omron fh series Specifications

General

Brand	Omron
Model	fh series
Category	Machine Vision Systems
Language	English
