PLC Master Calibration
Refer toKey Points for Adjustment under PLC Master Calibration in the Vision System FH/FHV Series
Processing Item Function Reference Manual (Cat. No. Z341).
Vision Master Calibration
Refer to Key Points for Adjustment under Vision Master Calibration in the Vision System FH/FHV
Series Processing Item Function Reference Manual (Cat. No. Z341).
Calibration Support Tool
Symptom Parameters to adjust Correction
The unit number is set to
None and cannot be se-
lected.
-
Check whether there are any processing items that re-
tain calibration data that are registered in the current
scene.
The setting data is initial-
ized every time the Tool-
box is opened.
• Tool Settings Save But-
ton
• Tool Settings Load But-
ton
This is the specified behavior. If you need to save the
settings data, use the Save button in the Toolbox. The
saved settings can be loaded with the Load button.
How do you rotate the
graphic display for better
visibility?
• Standard axis
• Axis direction
• Direction of rotation
You can rotate the graphic display along the standard
axis, axis direction, and rotation direction on the
Display setting tab page.
10-9-4
Alignment
This section will use two Cameras to describe the procedures for setting the alignment flow and
executing alignment.
Example 1: Alignment Flow Example (Position Data Calculation and Axis Movement Conversion) for
Two Cameras
Camera Image Input processing item
Select Camera 0.
↓
Calibration Data Reference processing item
Select the Vision Master Calibration or PLC Master Calibration
processing item on the calibration scene with the Calibration
Data Reference.
↓
Position measurement processing item
Measure the position of the alignment marks or the position of
a special feature of the workpiece from the image in Camera 0.
To output the actual coordinates of the position, set
Calibration on the Output parameter tab page to ON.
Out of the general measurement processing items
(Inspections and Measurements), you can use processing
items with measurement results that have an X and Y in the
calculation strings.
Set the workpiece in reference position and then set the refer-
ence position.
↓
10 Advanced Usage
10 - 61
FH/FHV Series Vision System User’s Manual (Z365-E1)
10-9 Positioning workpieces for stage and
robot applications [Alignment Function]
10
10-9-4 Alignment
