Label Setting Region
Item
Setting value
[Factory default]
Description
Data Type
• [Unit data (No.)]
• Unit data (ident)
• System data
• Scene variable
• System variable
Sets the unit specification method for targets for which to carry
out the label setting. The setting details vary depending on the
specification method. Setting of title The place where {0} in char-
acter string is the data notation set by Data Type.
The setting details vary depending on the specification method.
Target unit No. 0 to No. of units in
the display target
scene - 1 [0]
Specifies the unit to be the target for the label setting.
The units that are registered for the scene that is the target of
the normal dialog box will appear in the combo box. Select the
processing unit to set.
Unit label
• [Unchecked]
• Checked
This is available when Unit data (No.) or Unit data (ident) is se-
lected in the Data Type.
When using the unit label to specify the unit to be the target for
the label setting, select this and set the unit label.
Target data No. 0 to 9999999 [0] Specifies the data to be the target for the label setting.
Enter the data number for the unit that is specified by the Target
unit No..
Data reference
button
- You can select the data number directly to enter it, or you can
enter it with the Data reference button. Click the Data
reference button to select the target data in the Data reference
dialog box.
Data ident - Sets when Unit data (ident) is selected in the Data Type.
Use the unit data (identifier name) to specify the unit to be the
target for the label setting.
Ident 0
Ident 1
- These are available when System data is selected in the Data
Type.
Specifies the system data to be the target for the label setting
using the identifier information 0 and identifier information 1. Re-
fer to the Vision System FH Series Macro Customize Functions
Programming Manual (Cat. No. Z367) - system data list.
Scene variable - This is available when Scene variable is selected in the Data
Type.
Specifies the scene variable to be the target for the label setting
using the scene variable name.
System variable - This is available when System variable is selected in the Data
Type.
Specifies the system variable to be the target for the label set-
ting using the system variable name.
Precautions for Correct Use
If you change the measurement flow after you create a custom dialog box, change the target
unit number to match the edited measurement flow.
8-4-3
Launching Your Custom Dialog Box
1 In the Main Window, select Custom dialog from the Tool menu.
The custom dialog box that is set for Select target dialog is displayed.
8 Setting Windows
8 - 83
FH/FHV Series Vision System User’s Manual (Z365-E1)
8-4 Editing contents are not reflected when you confirm the Sensor Controller after edit a layout by remote control
[Custom Dialog Tool]
8
8-4-3 Launching Your Custom Dialog Box
