8-4
Editing contents are not reflected
when you confirm the Sensor Con-
troller after edit a layout by remote
control [Custom Dialog Tool]
You can create a customized settings dialog box on the Sensor Controller and display it instead of the
normal settings dialog boxes for each processing item.
This allows you to hide parameter settings that must not be changed during normal operation, and
show only the parameters that are necessary. You can also create a settings dialog box that allows the
operator to change the settings for more than one processing unit.
8-4-1
Flow of Use
From the Custom dialog tool menu, display the list of custom dialog boxes.
↓
Custom dialog tool.
↓
Set the custom dialog box properties.
↓
Display and edit the normal dialog box edit display as necessary.
↓
Specify the target dialog box to use.
↓
Use the Custom dialog menu to call the target dialog box.
↓
Save the settings of the custom dialog box (Data save or Save to file)
8-4-2
Custom Dialog Tool
Use the following procedure to create a custom dialog box.
1 In the Main Window, select Custom dialog tool from the Tool menu.
The List of dialog display area is displayed. The Custom Dialog Tool has the following display
areas: Dialog Box List Display Area, Dialog Box Properties Display Area, and Preview Area.
8 Setting Windows
8 - 64
FH/FHV Series Vision System User’s Manual (Z365-E1)
To Next Page
