9-1-2
External Drive Names
l
Drive Names for USB Devices
Sensor Controller has two or four USB connectors. If more than one USB memory device is insert-
ed, specify the USB memory drive that is to be the destination.
• FH series/FHV series:
USB devices are assigned as drives E:\, F:\, G:\ and H:\ in the order in which they are inserted.
l
Drive Name of Memory Card
• When FH series Sensor Controller is used SD memory card, "M:\" is assigned as a fixed drive.
• When FHV series is used microSD card, "E:\" is assigned as a fixed drive.
Precautions for Correct Use
Box-type Controllers Box
If USB memory devices are separately connected to adjacent USB connectors, the contact be-
tween USB memory devices may possibly lead to failure or damage.
USB hub
When connect the USB memory using USB hub, the drive name can be differ as a previous
saved. If you want fixed name, directly connect the USB port without USB hub.
9-1-3
Using External Storage Devices
Use the following procedure to remove the external storage device.
This procedures are available in FH series/FHV series.
1 In the Main Window, select System information from the Function menu.
The system information is displayed.
2
Click Drive information.
Each drive information is displayed.
If an external storage device is inserted, the Eject button is displayed.
3
To remove the USB memory device, click the Eject button.
• When the USB Memory Can Be Removed
9 Saving/Loading Data
9 - 5
FH/FHV Series Vision System User’s Manual (Z365-E1)
9-1 Saving Data to the FH series/FHV series
9
9-1-2 External Drive Names
