Item
Setting value
[Factory default]
Description
Text Setting - Sets character data to display.
Data Type
• [Direct]
• Variable
Sets text data to display on the button.
• Direct:
Directly input to the Text Data.
• Variable:
Specify a system variable or a scene variable of character
string type that defines a character string to display.
Text Data 0 to 128 characters Specifies text data to display on the button.
Data Type (Se-
lected)
• [Direct]
• Variable
Sets text data to display at the button selection.
• Direct:
Directly input to the Text Data.
• Variable:
Specify a system variable or a scene variable of character
string type that defines a character string to display.
Text Data (Se-
lected)
0 to 128 characters Specifies text data to display at the button selection.
Font Setting - Sets display font.
Size 1 to 100 [10] Sets the font size.
Style
• Bold
• Italic
• Underline
• Strikeout
Sets the font style.
Check the box of your desired style.
Color Setting - Sets the fore color, background color, and the select color at se-
lection.
Fore Color R: 0 to 255 [16]
G: 0 to 255[16]
B: 0 to 255[16]
Sets the character color.
Back Color Set the button color in normal state.
Select Color Set the button color in select state.
Precautions for Correct Use
• Set a subroutine name to specify in Macro Func. in accordance with the following rules.
* + Single-byte alphabetical character + Single-byte alphanumeric character and _
(underscore)
Example:*MEASUREDISP
• In Control, if using a macro RaiseOptionEvent to operate, then specify the control command
in the event number, and the control parameters in the parameter.
8-3-18
Text Display Window (MDI_DispText.dll)
Window part to display character strings.
This comprises the following elements.
• Text label
Details that can be set are as follows.
8 Setting Windows
8 - 47
FH/FHV Series Vision System User’s Manual (Z365-E1)
8-3 Arranging Windows [Layout Functions]
8
8-3-18 Text Display Window (MDI_DispText.dll)
