Item
Setting value
[Factory default]
Description
Data identifier/
number/varia-
ble
- Sets the identifier name of data to input numerical value.
The setting contents vary depending on Data type.
The input is up to 32 characters.
Unit data: External reference data number or identifier name
Scene variable or System variable: Variable name
System data or Global data: Identifier name
Upper limit
(Ident/Number)
Lower limit
(Ident/Number)
- Sets the upper limit/lower limit numerical values that can be input.
The setting contents vary depending on Data type.
The input is up to 32 characters.
Unit data: Numerical value or External reference identifier name
Scene variable or System variable: Numerical value or Variable
name
System data or Global data: Identifier name
Decimal digits 0 to 10 [0] Sets the number of digits after the decimal point for the data to in-
put numerical value.
Status - Set the status of Window Part.
Front/Back - Specifies the variable to store the status of the numerical value in-
put window from the variable allocation window.
However, only scene variables and system variables can be
specified.
Refer to Assigning variables on page 5 - 60.
When the variable value is positive. : Move the window to the
front.
When the variable value is negative. : Move the window to the
back.
When the variable value is 0. : Do not move the window.
Operation - Sets this when calling a macro subroutine after inputting numeri-
cal values and updating data.
Macro subrou-
tine after edit
- This is effective only when Unit data is selected in Data type and
a macro is specified in Unit.
Control - Sets this when changing the status of the numerical value input
window using a macro.
Control ID 0 to 999 The ID used to identify the operation target if using the macro Rai-
seOptionEvent relationship to carry out operations.
Precautions for Correct Use
• Set subroutine name to specify in Operation in accordance with the following rules.
* + Single-byte alphabetical character + Single-byte alphanumeric character and _
(underscore)
Example:*MEASUREDISP
• In Control, if using a macro RaiseOptionEvent to operate, then specify the control command
in the event number, and the control parameters in the parameter.
8-3-23
Data Settings Button Window (MDI_SetDataBtn.dll)
Window part that displays on the main screen as a button to set parameters such as processing unit.
This comprises the following elements.
• Settings button
Details that can be set are as follows.
8 Setting Windows
8 - 55
FH/FHV Series Vision System User’s Manual (Z365-E1)
8-3 Arranging Windows [Layout Functions]
8
8-3-23 Data Settings Button Window (MDI_SetDataBtn.dll)
