A-10
Memory Usage Guidance For Proc-
essing Items
Free space is required in the application memory in order to add a processing unit to the measure-
ment flow. The amount of free space required in memory consists of both the amount necessary to
add a processing unit to the measurement flow, and the amount necessary to configure settings for
the added unit and execute measurement.
When adding a new processing unit to the measurement flow, or if the memory becomes insufficient
when settings are configured, refer to the table below for the approximate amount of memory used
and delete a processing unit from the measurement flow or adjust the processing unit settings.
The amount of used memory and free data memory can be checked from the menu of Memory Con-
sumption Monitor on the Measurement Management Bar or the system menu.
Refer to 3-4 Checking the Memory Consumption and Percentage of Memory Used on page 3 - 28 and
3-3 Checking System Information [System Information] on page 3 - 24. To adjust each processing unit,
refer to the section for each processing item in the Vision System FH/FHV Series Processing Items
Reference Manual (Cat. No. Z341).
Item
Approximate memory usage
Main settings that affect change of
memory used
Adding to
measurement
flow
Change due to
settings
Search Approx. 2 KB Approx. 544 MB
(for mono-
chrome image)
Approx. 1,609
MB (for color im-
age)
Model registration figure, model parameters,
saved settings of model registration image,
image size, number of detections, whether
image is color or monochrome.
Flexible Search Approx. 2 KB Approx. 2,665
MB (for mono-
chrome image)
Approx. 7,856
MB (for color im-
age)
Model registration count, model registration
figure, model parameters, image size, wheth-
er image is color or monochrome.
Sensitive Search Approx. 8 KB Approx. 1,088
MB (for mono-
chrome image)
Approx. 3,218
MB (for color im-
age)
Model registration figure, model parameters,
image size, whether image is color or mono-
chrome.
ECM Search Approx. 2 KB Approx. 2 MB Model registration figure, error model regis-
tration figure, extraction amount of edge ex-
traction, image size.
EC Circle Search Approx. 24 KB Approx. 1 MB -
Shape Search II Approx. 6 KB Approx. 57 MB Model registration figure, model parameters,
saved settings of model registration image,
image size, shape of edge in image.
Appendices
A - 30
FH/FHV Series Vision System User’s Manual (Z365-E1)
